• Adjustable Input Sensitivity Control
  • Selectable 90 or 125Hz, 12dB per octave, front highpass crossover with defeat
  • Continuously variable, 12dB per octave, 30 to 600Hz rear highpass or lowpass crossover with defeat
  • Separate LED indicators for power-on and protection
  • Separate front and rear adjustable input sensitivity controls
  • Adjustable 0 to 15dB "twin t" 45Hz bass boost
  • Muting circuitry for soft turn-on and turn-off
  • Fully complimentary output stages
  • Advanced overload and thermal protection circuitry
  • High current bussbars for all high current, high voltage stages
  • PWM MosFet power supply
  • Gold plated high current power and speakers terminals
  • Gold plated signal input RCA jacks
  • Unique chrome powder coated finish
  • Die-cast gold plated logo badges
  • Isolated mounting feet
  • QLINKable
    Frequency Response +/-1dB, 20Hz to 20 kHZ
    Signal to Noise Ratio (A-weighted) >100dB
    Max Continuous
    Bridged Power @ 1% THD    		 150 watts x 2 into
    4 ohms @ 14.4 Vdc
    Max Continuous Power
    per Channel @ 1% THD    		 75 watts x 4 into 2 ohms @ 14.4 Vdc
    Nominal Continuous Power per Channel @ 1 % THD 60 Watts x 4 into 4 ohms @ 14.4 Vdc
    IASCA/USAC Power Rating 50 Watts x 4 into 4 ohms @ 12.5 Vdc
    Minimum Load when Bridged 4 Ohms
    Minimum Load per Channel 2 Ohm
    Input Signal Voltage Range 0.1 volts to 2 volts
    Crossover Type Cont. Variable Linkwitz Riley HP,LP
    Input Impedance, Standard/Balanced 12kOhms, n/a
    Crossover Slope 12 dB per octave
    Crossover Frequency Range 90 or 125Hz Highpass / 30-600Hz Lowpass
    Factory Crossover Setting 90Hz Highpass
    Hi-level Input yes (US models only)
    Bass Boost 0- to +15dB @ 45 hZ
    Power Supply Voltage 10Vdc to 15.5Vdc
    Recommended Fuse 40 amp
    Dimensions, Chasis 13.86L x 8.50W x 2.00H
    Dimensions, Overall 14.86L x 8.50W x 2.10H
